Impact Resistant Fixed windows - Series 535

GENERAL

Impact Resistant Fixed windows as shown in the architectural drawings shall be Series 535 as manufactured by  SOL-A-TROL Aluminum Products, Miami Fla. Tested in accordance with Miami-Dade county protocol to a design pressure of +86.7, -100 psf.

MATERIAL

Extruded aluminum 6063-T6 (Alloy and Temper)

CONSTRUCTION

The window frame shall be of .062” minimum thickness and 3 ¾” deep. All frame members shall be joined by #10 x 7/8” Stainless Steel sheet metal screws. (2 per corner)

MUNTIN

Integral muntin with profile similar to single hung meeting rail.

FINISHES

Electro-statically applied baked enamel.
Clear Anodized.
Bronze Hardcoat.
Kynar 500

GLAZING

The glass shall be as specified under Glass and Glazing section and product approval, and held in place with extruded snap-in type glazing bead.
